Description
The cable drum of a hydraulic motor type crane is a device that uses a hydraulic motor as the driving source to automatically retract and release cables, and provides power supply for wet spraying machine operation through a collector ring.
Working Condition
1. For elevations below 2000m, additional high-altitude components are required for elevations above 2000m
2. Temperature: -40 ° C to 50 ° C
3. Relative humidity of the air: The average monthly humidity in a wet month is 90%
4. The voltage fluctuation range of the power supply unit’s power grid shall not exceed 5% of the rated voltage
Features
FEATURE 1
The hydraulic motor type cable reel has powerful power, precise control, and efficient energy-saving characteristics, which can adapt to various working conditions.
FEATURE 2
It also has low noise during operation and will not produce excessive noise pollution.
FEATURE 3
These advantages have won the trust of customers and also extended the service life of the drum.
Technical Data
| Model | 10mm² | 16-m² | 25mm² | |||||||||
| JQ-15-l | 25 | 20 | 15 | |||||||||
| JQ-30-l | 45 | 40 | 30 | |||||||||
| JQ-60-l | 75 | 70 | 60 | |||||||||
| JQ – | | | ||||||||||||
| Model | 10mm² | 16mm | 25mm² | |||||||||
| JQ-15-1 | 25 | 20 | 15 | |||||||||
| JQ-30-1 | 45 | 40 | 30 | |||||||||
| JQ-60-l | 75 | 70 | 60 | |||||||||
| Model | E | F | D1 | D2 | M | N | P | H | G(kg) | |||
| JQ-15-1 | 80 | 83 | 350 | 550 | 250 | 300 | 360 | 325 | 150 | |||
| TQ-30-1 | 80 | 83 | 400 | 650 | 250 | 800 | 360 | 375 | 170 | |||
| JQ-60-1 | 80 | 83 | 400 | 750 | 250 | 300 | 360 | 425 | 210 | |||
